One operating point at a time is not the problem. The cycle is.

Anyone can trade NOx against fuel at a single point. The work is deciding which points are worth the test-cell time, and then holding the whole cycle inside its limits while you move them. This demo walks that, on a WHSC cycle, in four steps.

What this is, precisely. The cycle is the regulation World Harmonised Stationary Cycle definition — 12 modes, mode lengths as published — denormalised onto a synthetic demo engine (6-cylinder · 7.0 L · heavy-duty). The response surface behind it is hand-authored to behave the way a compression-ignition engine does. It is not a calG fit and contains no customer data. In the product, a model fitted in calG from your own dynamometer data goes here, and the same steps run against it.

Synthetic demo engine · 6-cylinder · 7.0 L · heavy-duty · World Harmonised Stationary Cycle (WHSC), 12 modes over 1895 s

Idle is 22% of the cycle and 0% of the result

A stationary cycle is a weighted mean of brake-specific numbers, so a mode’s influence is its time weight times its power. Idle runs for 420 s of 1895 s and makes no brake power, so it cannot move the result at all. Mode 10 is the reverse — 2.6% of the time, 12.5% of the NOx. The top three modes carry 37% between them.

Getting this ranking wrong is how programmes spend weeks of test-cell time on points that cannot change the outcome. It is the first thing calG puts in front of you, and it is why the next step matters more than the optimisation itself.

ModeSpeedTorquePowerWeightShare of cycle NOx
M111160rpm543Nm66kW10.6%13.3%
M101800rpm1061Nm200kW2.6%12.5%
M21480rpm1098Nm170.2kW2.6%10.8%
M91480rpm549Nm85.1kW6.6%10.5%
M41480rpm769Nm119.2kW4.0%9.8%
M31480rpm275Nm42.6kW13.2%8.9%
M71320rpm769Nm106.3kW4.0%8.9%
M51160rpm1086Nm131.9kW2.6%8.5%
M121160rpm271Nm32.9kW13.2%7.1%
M61000rpm265Nm27.8kW10.6%4.9%
M81320rpm275Nm38kW7.9%4.8%
Idle600rpm0Nm0kW22.2%0.0%

Nothing here is saved. There is no scenario to store, no account, and no export — reload the page and it starts from the baseline again. In calG, this is where scenarios, validation evidence and ECU-ready maps come out.

Why point selection comes first

A stationary cycle is a weighted mean, so a mode’s influence is its time weight times its power. Optimising a point that carries 2% of the cycle is test-cell time spent on nothing. calG puts that ranking in front of you before any optimisation starts.

What the product adds

Your own data and your own fitted models, your control variables read from your data columns, DoE generation, SCR and aftertreatment, transient cycles, validation evidence, and ECU-ready maps out of the other end.

Try it on your engine

A 30-day trial runs the full workflow on your own data, on your own machine.
